Pultszkenner Datalogic Magellan

Figure 2-8. Medium Shelf Models 8302/8304/8402/8404 Cutout Dimensions

Counter Cutout

Models 8302/8304/8402/8404 (Medium Shelf) Minimum Cutout Max. Radius = 0.25" (0.635cm) 4x Dimensions 15.825" (40.2cm) min. 11.625" (29.53cm) min.	Optional Leveling Feet 1.76" (4.47cm) 10.83" (27.5cm) Leveling Feet 6.89" (17.5cm) Shelf/ Support Rails
Models 8302/8304/8402/8404 (Medium Shelf) Supports 4.08" (103.6mm) Support Rails Liquid Drainage Liquid Drainage

Figure 2-9. Medium Shelf Models 8302/8304/8402/8404 Scanner Reference Dimensions

Models 8302/8304/8402/8404 (Medium Shelf) Scanner Reference Dimensions

4.59" (11.7cm)

11.5" (29.21cm ± 0.1cm)

5.19" (13.2cm)

9.27" (23.6cm ± 0.2cm)

7.5" (19.05cm)

4.08" (10.36cm ± 0.15cm)

15.71" (39.9cm ± 0.15cm)

Technical Guide

2-13

FLIP-TOPSERIES

PRODUCT SPECIFICATIONS

460 MODEL

FEATURES

Dimensions:
(width x depth x height)

18.1 x 6.8 x 4.0 inches Shipping weight: 460 x 172 x 102 mm

15 lbs 6.8 kg

Tested to last beyond 2 million operations
Flip-lid opens fully to 80o providing easy access to the contents of the till for the life of the drawer
Robust latch withstands slamming and closes even with a light touch
Single media slot offers additional under till storage
Till with locking cover provided with every unit, locking cover fully encloses media

ADVANCED SECURITY OPTIONS

Advanced Drawer Lock Options

The Flip-Top cash drawer can feature the added security of being randomly keyed from100 mutually exclusive lock codes. *

Available in Black and Beige, with either a painted or stainless steel lid
Four function lock
Closed and latched drawer status switch
Random keying from 4 lock codes is standard, other lock and keying options are available

Advanced Till Cover Lock Options

* Other lock/keying options are available, contact your APG representative for more information.

AVAILABLE HARDWIRED INTERFACES

437A Epson TM Hardwired Interface
422 TPG Hardwired Interface
468 IBM 46XX Series Hardwired Interface
XXX Other numbers indicate the DirectPRO® hardwired or a custom interface

Refer to Connectivity Guide at www.apgcashdrawer.com for interface cable detail.

OPERATING ENVIRONMENT
Storage Temperature -30oC to +50oC (-22oF to +122oF)

Operating Temperature 0oC to +40oC (+32oF to +104oF) Visit us on the web at www.apgcashdrawer.com

Relative Humidity (non-condensing)

10% to 95%

The locking till cover can feature the added security of being randomly keyed from160 mutually exclusive lock codes. *

Page 1 of 2

ACCESSORIES

Till comes standard with cash drawer, additional tills are available
Locking till cover is included with every till
Weighable coin cups are available in the standard 33.5 gram weight
The Flip-Top till accommodates a variety of currencies, contact your APG Representative for more information
Measurements are shown as width x depth x height

Standard Till

VPK-15FTC-01-BX

8 coin, 4-6 bills locations with removable divider to adjust bill spaces. Features integrated media storage.

17.5 x 6 x 3.5 inch 446 x 152 x 89 mm

Till and cover shown

Weighable Coin Cups

PK-15J-06-BX

• Standard tare weight for automated cash counting • Precision molded at 33.5 grams each cup
• Exact fit to each till
• Easy removal

• GOST
• TUV (Canada & US)

REGULATORY CERTIFICATIONS

CE
RoHS/WEEE

WARRANTY
Two (2) year limited warranty. A full warranty statement is available online at www.apgcashdrawer.com/support/warranty-statement.

APG Cash Drawer, LLC 5250 Industrial Blvd. N.E. Minneapolis, MN 55421

Phone: 763 571 5000 Fax: 763 571 5771

APG® Cash Drawer, the APG Cash Drawer logo, SerialPRO®, MultiPRO®, DirectPRO®, USBProTM, ParallelPROTM, POS–IntegratorTM,VasarioTM, POS–PodiumTM and Cash Drawer CaddyTM

are trademarks of APG Cash Drawer, LLC. M-43-109 Rev. A
